Mini-invasive Surg 2020;4:25. 10.20517/2574-1225.2019.66 © The Author(s) 2020.
Open Access Technical Note

Uniportal video assisted thoracoscopic left upper bronchial sleeve lobectomy in a pediatric patient

1Department of Cardiothoracic Surgery, Makassed Charitable Society Hospital, East Jerusalem, Palestine.

2Department of Pediatrics, Makassed Charitable Society Hospital, East Jerusalem, Palestine.

3Department of Thoracic Surgery, 251 Hellenic Airforce General Hospital, Athens 11525, Greece.

Correspondence Address: Firas Abu Akar, Department of Cardiothoracic Surgery, Al-Makassed Charitable Society Hospital, East Jerusalem, Affiliated to Al-Quds University School of Medicine, Jerusalem 97103, Palestine. E-mail: firasabuakar@gmail.com

    This article belongs to the Special Issue Minimally Invasive Thoracic Surgery
    Views:1617 | Downloads:283 | Cited:0 | Comments:0 | :454
    Science Editor: Noriyoshi Sawabata | Copy Editor: Jing-Wen Zhang | Production Editor: Jing Yu

    © The Author(s) 2020. Open Access This article is licensed under a Creative Commons Attribution 4.0 International License (https://creativecommons.org/licenses/by/4.0/), which permits unrestricted use, sharing, adaptation, distribution and reproduction in any medium or format, for any purpose, even commercially, as long as you give appropriate credit to the original author(s) and the source, provide a link to the Creative Commons license, and indicate if changes were made.


    Endo-bronchial tumors are sporadic in the pediatric population. Pneumonectomy is rarely indicated and best to be avoided if possible due to the morbidity it may cause. In children, preserving as much of the lung parenchymal tissue as possible is crucial and maintaining the integrity of the "still maturing" chest wall may reduce the risk of developing scoliosis and chest deformities in the future. The integration of minimally invasive surgical techniques and parenchymal sparing procedures rep-resents the best possible outcome for these patients. Of course, oncological principles should be re-spected when such a procedure is performed. We present the first report in the literature of a "left" upper lobe sleeve resection in an 8 year old patient via a single port video-assisted thoracoscopic surgery technique.


    Thoracic surgery has recently undergone significant transformation and evolution. The traditional (open) thoracotomy has started to lose its popularity and thoracoscopic surgeries have started to gain interest amongst most surgeons. This is largely because of the benefits in reducing the proportion of postoperative complications and an earlier return to normal life. Uniportal video-assisted thoracoscopic surgery (VATS) is the latest development in thoracoscopic surgery[1]. After a decade of developing and adapting thoracoscopic surgery to a variety of thoracic conditions, it has now become possible to perform the most complex procedures through this technique, especially in adults[2-4]. However, this is still rarely utilized in children due to the difficulty of instrumentation and the lack of experience. Neuroendocrine tumours compose a small percentage of lung tumors not exceeding 2% of the general population. Neuroendocrine tumors however, are considered the most common airway malignancy in children[5]. It is well-known and generally accepted that surgical resection is the ideal solution in these cases[5]. The rarity of these tumors usually results in a significant delay in their diagnosis and treatment, as it may be treated for a long time as a chronic infection or foreign bodies in the respiratory tract[6]. Since the first bronchial sleeve operation was performed in the 1940s[7], these operations have evolved to become the preferred procedure to avoid pneumonectomies[8], and have recently been performed via the uniportal VATS technique with excellent results[3,4]. Except in one case by Gonzalez-Rivas et al.[9], these operations have not been performed previously with the uniportal VATS technique. In his article, Gonzalez-Rivas et al.[9] performed a right upper sleeve lobectomy and tracheoplasty in a 10-year-old child for a carcinoid tumor in the right main bronchus. In the current study, we report the second successful case of bronchial sleeve resection in a child through the uniportal VATS technique in the literature, and the first to be performed on the left main bronchus in an 8-year-old child with satisfactory results.

    Case presentation

    A previously healthy 8-year-old female patient with a six-month history of fever and recurrent chest infections showed only partial improvement with antibiotics. A bronchoscopy was performed to rule out the presence of a foreign body, and to obtain samples for microbiology. A highly vascularised endobronchial mass arising from the left main bronchus and occluding the bronchus to the upper lobe was found [Figure 1]. Transbronchial biopsy and bronchoalveolar lavage were performed. Pathological findings revealed a typical carcinoid tumor and cultures grew Pseudomonas aeruginosa. i.v. antibiotics were given according to culture sensitivities and a 68Ga DOTATATE PET-CT was performed to exclude mediastinal and extrathoracic findings [Figure 2]. The case was discussed at the multidisciplinary team meeting and surgery was recommended. To avoid pneumonectomy at this young age, a bronchial sleeve resection was considered. Based on our experience in uniportal VATS operations in adults at a specialized and ultra-high volume tertiary center[10], and after gaining further experience in paediatric patients[11], we decided to perform the surgery via the uniportal VATS technique to reduce the risk of complications and surgical trauma.

    Figure 1. Bronchoscopic image showing a pedunculated mass occluding the left main stem bronchus

    Figure 2. 68Ga DOTATATE PET-CT shows high uptake in a left main bronchus mass

    Surgical technique

    Once under general anesthesia, isolated right lung ventilation was maintained with a 26 Fr “right” double lumen endotracheal tube. The patient was positioned in the right decubitus position [Figure 3]. The uniportal VATS approach required a 3-cm incision at the 5th intercostal space, along the anterior axillary line. A high definition thoracoscope with 30º/10 mm lens was inserted through the incision. Exploration of the pleural cavity revealed severe adhesions, probably due to recurrent chest infections. After adhesiolysis, a left upper bronchial sleeve lobectomy was performed. First, the left superior pulmonary vein was dissected free, encircled and then divided using Endo-GIA Stapler vascular reload (Endo GIATM Curved Tip Reload with Tri-StapleTM Technology). After that, branches of the pulmonary artery to the upper lobe were divided individually after tying with 0 silk thread or double clipped with polymer clips Click’aV PlusTM until the artery was completely separated from the upper lobe [Video 1]. The left main and left lower lobe bronchus were freed circumferentially by scalpel and surgical scissors before the lobe was retrieved inside a protecting bag. Frozen section confirmed disease-free margins. The inferior pulmonary ligament was divided, and the left main pulmonary artery was retracted laterally using 0 silk stitch encircled around the artery and fixed to the chest wall [Figure 4], to both avoid tension and facilitate the subsequent anastomosis respectively. The left lower lobe and left main bronchus were anastomosed end to end using a continuous PDS 4/0 double needled suture, starting from the medial aspect of the bronchus and ending by tying the suture at the lateral corner of the anastomosis [Video 1]. Upon completion of the anastomosis, an air-leak test was done and inflation of the lower lobe was ensured. After adequate hemostasis, a single 20 Fr chest tube was inserted through the same incision and the wound was closed in layers in standard fashion. The patient was successfully extubated and transferred stable to the pediatric ICU. The post-operative course was uneventful otherwise and the patient was stepped down to the ward 24 h post-surgery. Postoperative chest X-ray showed good expansion of the left lower lobe [Figure 5]. The chest tube was removed on post-operative day 5, and the patient was discharged home on post-operative day 6 in an excellent condition. Follow-up bronchoscopy (at 1 and 6 months after the procedure) revealed intact anastomoses with no evidence of stenosis. At 9 months’ follow-up, the patient is asymptomatic and does not have any complaints.

    Video 1

    Surgical video showing uniportal video-assisted thoracoscopic surgery of a left upper bronchial sleeve lobectomy in a pediatric patient

    Figure 3. Right decubitus positioning of the patient

    Figure 4. Intraoperative image showing the way of retracting the left main pulmonary artery to improve exposure of the bronchus

    Figure 5. Postoperative chest X-Ray showing good inflation of the lung with no abnormalities


    Sleeve bronchial resection procedures are usually performed in adults to avoid pneumonectomy and associated morbidity. These operations are conducted in cases of central or endo-bronchial tumours. In children, bronchial sleeve resections are extremely uncommon and rarely indicated due to the paucity of lung malignancies in the pediatric population in general, especially endobronchial tumors. A review of the literature only yielded one case of a bronchial sleeve operation performed via the uniportal VATS technique in a 10-year-old child who had a carcinoid tumour in the right main bronchus[9]; there were otherwise only a few reports on pediatric sleeve resection through the traditional open thoracotomy approach[9,12]. It is well known that VATS can significantly reduce complications and surgical trauma, contribute to earlier recovery and expedite the return to normal life for patients[13].

    There are additional benefits of thoracoscopic surgery, especially in children, such as the avoidance of scoliosis and preventing breast asymmetry in females due to the damage that may occur in chest wall muscles from traditional open thoracotomy[14-16]. Therefore, the thoracoscopic approach to these pediatric cases is much more desirable and should be strongly encouraged. There are still some obstacles that may limit the applicability of this technique in children however, with the learning curve being particularly steep. The operative field available in the child’s pleural space is limited, which can lead to extreme challenges with instrumentation. Another difficulty that one may face during surgery is the complexity of lung isolation due to the unavailability of the double-lumen tube for all ages, which poses a challenge to the surgeon and anesthesiologist. This is on top of the lack of instruments specially designed for pediatrics. We usually use traditional instruments to perform uniportal VATS in infants[11], or those designed for adults in older children.

    In conclusion, we strongly believe in the value and benefits of uniportal VATS surgery, especially in pediatric patients. Complex operations via the uniportal VATS approach as described is feasible in children. However, experience in uniportal VATS is necessary, and these operations must be performed in specialized and high-volume centers that contain all the necessary facilities. There is a need to develop specialized equipment specific for children for such operations to make it more manageable.


    Authors’ contributions

    Conception and design of the study, and performed data analysis and interpretation: Abu Akar F, Shaqqura B

    Performed data acquisition, as well as provided administrative, technical, and material support: Abu Akar F, Rumman N, Soultanis KM

    Availability of date and materials

    The authors declared that all data that support our findings can be found in our database and archive at Al-Makassed Hospital. Data can be deposited into data repositories or published as supplementary information in the journal.

    Financial support and sponsorship


    Conflicts of interest

    All authors declared that there are no conflicts of interest.

    Ethical approval and consent to participate

    Ethical approval and consent was obtained from the patient’s parents to publish the article.

    Consent for publication

    Not applicable.


    © The Author(s) 2020.


    • 1. Passera E, Rocco G. From full thoracotomy to uniportal video-assisted thoracic surgery: lessons learned. J Vis Surg 2017;3:36.

      DOIPubMed PMC
    • 2. Abu Akar F, Gonzalez-Rivas D, Ismail M, Deeb M, Reichenshtein Y, et al. Uniportal video-assisted thoracic surgery: the Middle East experience. J Thorac Dis 2017;9:871-7.

      DOIPubMed PMC
    • 3. Abu Akar F, Yang C, Lin L, Min SJ, Jiang L. Intra-pericardial double sleeve uniportal video-assisted thoracoscopic surgery left upper lobectomy. J Vis Surg 2017;3:51.

      DOIPubMed PMC
    • 4. Soultanis KM, Chen Chao M, Chen J, Wu L, Yang C, et al. Technique and outcomes of 79 consecutive uniportal video-assisted sleeve lobectomies. Eur J Cardiothorac Surg 2019;56:876-82.

    • 5. Potter SL, HaDuong J, Okcu F, Wu H, Chintagumpala M, et al. Pediatric bronchial carcinoid tumors: a case series and review of the literature. J Pediatr Hematol Oncol 2019;41:67-70.

      DOIPubMed PMC
    • 6. Yu DC, Grabowski MJ, Kozakewich HP, Perez-Atayde AR, Voss SD, et al. Primary lung tumors in children and adolescents: a 90-year experience. J Pediatr Surg 2010;45:1090-5.

    • 7. Zwischenberger JB. Atlas of thoracic surgical techniques. 1st ed. Philadelphia, PA: Saunders/Elsevier; 2010. pp. 73-90.

    • 8. Shi W, Zhang W, Sun H, Shao Y. Sleeve lobectomy versus pneumonectomy for non-small cell lung cancer: a meta-analysis. World J Surg Oncol 2012;10:265.

      DOIPubMed PMC
    • 9. Gonzalez-Rivas D, Marin JC, Granados JP, Llano JD, Cañas SR, et al. Uniportal video-assisted thoracoscopic right upper sleeve lobectomy and tracheoplasty in a 10-year-old patient. J Thorac Dis 2016;8:E966-9.

      DOIPubMed PMC
    • 10. Abu Akar F, Gonzalez-Rivas D. Training in an ultra-high-volume center. Video-assist Thorac Surg 2018;3:17.

    • 11. Shaqqura B, Rumman N, Gonzalez Rivas D, Abu Akar F. Uniportal video-assisted thoracoscopic lobectomy in a 9-week-old patient. Interact Cardiovasc Thorac Surg 2020;30:327.

    • 12. Rizzardi G, Marulli G, Calabrese F, Rugge M, Rebusso A, et al. Bronchial carcinoid tumours in children: surgical treatment and outcome in a single institution. Eur J Pediatr Surg 2009;19:228-31.

    • 13. McKenna RJ Jr, Houck W, Fuller CB. Video-assisted thoracic surgery lobectomy: experience with 1,100 cases. Ann Thorac Surg 2006;81:421-5. discussion 425-6

    • 14. Korovessis P, Papanastasiou D, Dimas A, Karayannis A. Scoliosis by acquired rib fusion after thoracotomy in infancy. Eur Spine J 1993;2:53-5.

    • 15. Vida VL, Tessari C, Fabozzo A, Padalino MA, Barzon E, et al. The evolution of the right anterolateral thoracotomy technique for correction of atrial septal defects: cosmetic and functional results in prepubescent patients. Ann Thorac Surg 2013;95:242-7.

    • 16. Cherup LL, Siewers RD, Futrell JW. Breast and pectoral muscle maldevelopment after anterolateral and posterolateral thoracotomies in children. Ann Thorac Surg 1986;41:492-7.
